Product Details
Place of Origin: China
Brand Name: WONSUN
Certification: CE
Model Number: DZ-830 DC brushless motor barrier
Payment & Shipping Terms
Minimum Order Quantity: 1PC
Price: Negotiable
Packaging Details: Packed in bubble wrap firstly, and then reinforced with carton for outer packing.
Delivery Time: 3-7 working days after received your payment
Payment Terms: T/T,Western Union,Money Gram, Trade Assurance,Paypal etc.,
Supply Ability: 1000 Sets/Month
Product Name: |
Fence Arm Automatic Barrier Gate Automatic Parking Gate Barrier With Loop Detector |
Driving Method: |
Dc Brushless Motor |
Rated Voltage: |
DC24V |
Working Temperature(motor):: |
-35℃~+60℃ |
Rated Power: |
160W |
Output Power：: |
56.8N.m |
Product Name: |
Fence Arm Automatic Barrier Gate Automatic Parking Gate Barrier With Loop Detector |
Driving Method: |
Dc Brushless Motor |
Rated Voltage: |
DC24V |
Working Temperature(motor):: |
-35℃~+60℃ |
Rated Power: |
160W |
Output Power：: |
56.8N.m |
Fence Arm Automatic Barrier Gate Automatic Parking Gate Barrier With Loop Detector
If any interest, please contact me freely.
Email: keira@wonsunbarrier.com
Skype: zimin1314
Whatsapp: +86 185 0748 1610
Wechat: Keira_Xia
2. Electrical installation, wiring diagram
3. Features
3.1 The running speed can be adjusted from 1.5s to 8s
3.2 Can be quickly interchanged
3.3 Open the barrier gate by motor wheel when power off ,automatically reset after power on
3.4 Loop detector connector is available.
3.5 Wireless remote control control open/close
3.6 Auto reverse function(force adjustable)
3.7 Auto-delay when closing(adjustable)
3.8 24V backup battery interface(Can be charged by using solar energy)( optional)
| Arm type | Arm Length(L) | Operation time(S) | Height between arm and ground (M) |
| Straight arm | 6m≥L>5m | 5S | H=0.83m, height of arm center from ground level |
| 5m≥L≥4.5m | 4S | ||
| 4.5m>L≥3m | 3S | ||
| 90°folding arm | L≤5m | 5S | |
| 180°folding arm | L≤5m | 5S | |
| Two fence arm | 5m≥L≥4m | 6S | H=0.9m,height of arm center from ground level |
| 4m>L≥3m | 3S | ||
| Three fence arm | 5m≥L≥4m | 6S | H=1.5m,height of arm center from ground level |
| 4m>L≥3m | 5S |
Arm direction definition:
Equipment installation
Please select the correct type of barrier gate according to the specifications of the pace,and then fix the barrier
cabinet with expansion bolts(refer to Figure 3).
After determined the position,the barrier gate foundation should be done according to the site conditions,and also
make the cast-in-place basement for the non-concrete ground.
FAQ
1-Can you install using loop detector or pressure sensor on it?
Yes,the stanadard advertising barrier gate have loop detector and pressure sensor.
2-How about the guarantee and after sale service?
We have 1 year quality guarantee, We own well tranied and passional sales & aftersale services who can speak fluent English language.
3-How long is the leading time?
For standard item
10-50 sets:5 working days
50-100 sets:7-10 working days
200-500 sets:10-15 working days
For special item, or need custom design package or logo, need 3-10 working days longer.
4-How about the payment terms?
TT,western union,our company already joined the trade assurance,it will highly protect your order security.
Wonsun is a professional manufaturer for barrier gate, boom barrier, sliding gate motor. If any interest, please contact me freely.
Email: keira@wonsunbarrier.com
Skype: zimin1314
Whatsapp: +86 185 0748 1610
Wechat: Keira_Xia
